LCM module electrostatic protection scheme

一、Scheme protection circuit diagram

 LCM模组静电防护方案

二、Application Environment

1. Mobile LCM module

2. Industrial control small size LCM

3. High electrostatic protection requirements



三、Explanation of the plan

1. The power port adopts OVE2632A1 5V/15pF/DFN1006 package

2. The signal port adopts 0VE1432A1 5V/3pF/DFN1006 package

3. Can pass GB_T17626.2-2006 (IEC61000-4-2) contact 8KV, air 15KV test (test board)
